Cabo Booth D

The Cabo aluminum extrusion profile system is an elegant and versatilesolution for all of your display needs. Featuring a sleek silver anodized finish, the Cabo is the perfect solution for tradeshow booths, retail environments, pop up shops, or any place aluminum framing is needed. The profiles are available in standard 40mm and 80mm profile widths and in different shapes allowing you to turn your display vision into reality. Promote your company, new products, etc with custom dye sublimated fabric graphics. 12mm x 3mm silicone beading (SEG) is sewn around the perimeter of each fabric panel for easy installation and removal of your graphics. Choose from one of our pre designed configurations or contact us for a quote on something totally custom.

• Display Dimensions: 354” W x 172.2”H x 239.8”D
• Graphic Size: See Template Page
• Graphic Material: Dye-Sub Black & White Fabric
• Graphic Finishing: 12mm x 3mm silicone beading is sewn around the perimeter of the fabric graphic. Silicone beading is hidden from view once installed.
• Display Construction: Extruded aluminum profile frame with aluminum and steel components
• Shipping Weight:
  • 775 lbs (frame only) - LTL ONLY
  • 810 lbs (frame & graphic) - LTL ONLY
  • 35 lbs (graphic only) - UPS
• Shipping Dimensions: 102”L x 49.5”W x 44.5”H (Graphic Package & Hardware Only)
• Graphic Turn Around Time: 5 business days after proof approval for up to 2 booths
• Availability: PFC



Template
Specsheet
Images

Disclaimer:

We highly recommend that end users hire a professional labor team for the construction of their trade show exhibit. While we may provide guidance or assistance in the planning process, we do not assume responsibility for any accidents, mistakes, or damages that may occur during the build or operation of the exhibit. It is the sole responsibility of the end user to ensure the safety, quality, and compliance of their exhibit, including adherence to local regulations and industry standards. By proceeding with the construction of the exhibit, the end user acknowledges and accepts full responsibility for any risks or liabilities associated with the build process.

Before finalizing your exhibit display purchase, we strongly recommend researching the engineering stamp requirements for your respective venue. While our Modco builds are tested for quality and structural integrity, compliance with venue regulations is crucial. We offer the option of providing engineering stamps for an additional fee. Please note that there will be a delay in production if you request this service. Feel free to reach out for assistance or more information.
